Dingyu-75 Soundproof Window

一、 Basic Product Performance Ratings

二、Nine Key Advantages of the Product

1.Burglar-Resistant Locking Points: Multi-point interlocking mechanism enhances the burglary resistance of doors and windows

2.Ultra-High-Precision Aluminum Profiles and Hardware: High-precision extrusion ensures uniform gaps between frames and sashes, providing consistent sealing performance

3.Advanced German Design Philosophy for Profiles and Accessories: The entire structure and accessories adhere to German-style system window design standards

4.Standard hardware configuration with a load-bearing capacity of up to 80 kg; optional configurations support loads of up to 150 kg: Ensures stable opening and closing even for wide, heavy sashes with large glass panels

5.All gaskets are co-extruded EPDM foam; medium-pressure gaskets utilize a continuous bending process to minimize joints and enhance water and air tightness: One-piece, continuously bent gaskets with minimal joints ensure a seamless seal

6.Profiles are paired with a floor-drain drainage system: concealed floor drain drainage ensures a clean appearance and high drainage efficiency

7.Both inward- and outward-opening series feature a triple-seal system: a triple-ring seal structure effectively blocks rainwater, wind, sand, and noise

8.Glass utilizes continuously bent warm-edge spacers: warm-edge spacers reduce condensation on glass edges and provide superior thermal insulation

9.Optional 30.0mm-wide insulated spacer bars (exceeding the national standard of 24mm) provide superior thermal insulation. The spacer bar cavities can be optionally filled with PEX insulation material to further enhance thermal performance: the combination of wider spacer bars and cavity filling delivers thermal insulation performance that far exceeds that of standard thermal break windows compliant with national standards.

三、Product Specifications Table
